Polymer Candle Filter elements SUS 304
Description
The main filter layer of Pleated Filter mainly uses two materials：stainless steel wire mesh and stainless steel Sintered fiber.Stainless steel wire mesh is woven from stainless steel wire. Its pleated filter has the characteristics of smooth pores, easy cleaning, high temperature resistance, corrosion resistance, no wire mesh falling off, and long filtration cycle. Stainless steel sintered fiber is a porous deep filter material made of stainless steel fibers sintered at high temperature. Its pleated filter has the characteristics of high porosity, good air permeability, strong dirt holding capacity, and strong regeneration ability.
Candle filter elements and filter media
| Filter Raw Material | SUS304/316L |
| Filter Media | Metal sintering mesh stainless steel wire mesh |
| Filtration Rating | 1-200 Micro |
| Filter Length | 16-60 inch (406.4-1524mm) |
| Working Temp. | ≤350℃ |
| Allowed Pressure difference | 10 bar/14psi |
| Connector Type | 222/226/215/M36/M28/M24/M22/M20 |
Note: We can provide high quality polymer pleated candle filters to meet your specific requirements of polymer melt filtration applications.
Core advantages of melt filters
1. Ensure high purity and uniformity of the product:
It can effectively filter out gel particles, carbonized impurities, catalyst residues, dust and other tiny particles in the melt.
2. Enhance the mechanical properties and appearance of the product:
Impurities are stress concentration points, which can reduce the strength, toughness and durability of the product. After removing impurities, the comprehensive mechanical properties of the product have been significantly improved.
3. Enhance production continuity and efficiency:
It has a high dirt-holding capacity and can hold a large amount of pollutants before being completely clogged, thereby significantly extending the replacement cycle.
It has reduced the downtime caused by replacing filters or cleaning equipment, and improved the utilization rate and overall efficiency of the production line.
4. Enhance process stability:
It provides stable and consistent filtration resistance, which helps maintain the stability of melt pressure, flow rate and temperature, making the entire production process more controllable and smoother.
5. High temperature and high pressure resistance
It is usually made of stainless steel (such as 304, 316L), Hastelloy and other metals
Application Areas
1. Petrochemical: Refining, chemical production and separation and recovery of intermediate products.
2. Metallurgy: used for filtration of hydraulic systems of rolling mills and continuous casting machines.
3. Textile: Purification and uniform filtration of polyester melt during the drawing process.
4. Electronics and pharmaceuticals: pre-treatment and filtration of reverse osmosis water and deionized water, pre-treatment and filtration of cleaning fluid and glucose.
5. Thermal power and nuclear power: purification of lubrication systems, speed control systems, bypass control systems of gas turbines and boilers, purification of water supply pumps, fans and dust removal systems.
